TTM18

Description

Experience the Future of Tactical Thermal Optics with the ATN TTM-18

The ATN TTM-18 is a mission-ready, compact thermal sight built for adaptability and superior performance in demanding operational environments. Engineered for versatility, it functions as both a clip-on or stand-alone thermal riflescope while remaining compact enough for helmet mounting, enabling hands-free observation. It can also be deployed as a handheld monocular, enhancing situational awareness.

The TTM-18 is available in two configurations tailored to meet diverse mission needs: an ultra compact version and a compact version that is equipped with a 1000 yard LRF. Designed with military professionals in mind, the TTM-18 ensures unmatched operational flexibility and reliability in the field.

Choose Your Version

Available in two configurations to suit your needs:

ATN TTM-18

Ultra-Compact Version – Lightweight and streamlined for maximum portability.

ATN TTM-18 LRF

Compact LRF Version – Enhanced with a 1,000-yard laser rangefinder for extended capabilities.

Lightweight, Feature-Packed, and Built for Action

Weighing less than 10 ounces, the TTM-18 combines advanced functionality with effortless usability. Its ergonomic design allows for one-handed operation, with tactile, silent buttons that remain glove-friendly in any mission-critical scenario.

Unmatched Thermal Clarity

At the heart of the TTM-18 is a cutting-edge 12-micron, 640 x 480 ATN core, delivering industry-leading image sharpness. Powered by an advanced focal plane array and thermal image processor, it provides unparalleled thermal imaging performance.

Thermal sensor

640x480

12-Micron

<25mK NETD

Mission-Ready Design

Equipped with a flip-to-side QD mount, the TTM-18 enables a seamless transition between day optics and thermal vision while maintaining zero. Its rugged build and reliable performance make it a trusted companion for any tactical mission.

Multi-Mission Versatility

Optimized for small to medium caliber weapons, the TTM-18 excels as a true clip-on thermal sight. Its adaptability makes it equally effective as a stand-alone optic, a handheld viewer, or a helmet- mounted device.

IR Laser Pointer

The integrated IR laser pointer greatly boosts the TTM’s functionality. As a thermal imager, the TTM enables users to detect targets that are invisible to teammates relying on image intensifier night vision devices. With the TTM, a team member can locate a target and highlight it using the IR laser, providing precise guidance to the rest of the team. This advanced capability positions the TTM as a vital strategic asset.

Technical Specifications

Model	TTM 18
Modes of operation	Clip-On, Weapon sight, Monocular, Helmet mountable
Thermal sensor	12-micron, 640x480
Sensitivity / NETD	<25mK
Objective lens	25mm F1.0
Objective lens focus range	From 0.25 to infinity
Magnification	1x
Field of view	22.2 x 16.6
Diopter adjustment range	From -3 dpt to +3 dpt
Exit pupil diameter	20 mm
Eye relief	Unlimited
LRF	1000y/m (for LRF version)
Video and photo recording	Available on the device internal memory
Recording memory	Internal memory with capacity of 64 GB
Additional sensors	Compass, accelerometers, gyroscopes
Laser Pointer	850nm, Class 1 Eye Safe
Power supply	1 cell CR123 or 1 cell 18650 - rechargeable
Operational time with 1 battery	<3 hrs. (CR123), minimum 7 h. (18650)
Mount	NVG Dovetail mounting shoe compatible with variety of helmet mounts
IP rating	IP67
Dimensions	100x75x60 mm
Weight	300 g (non-LRF model), 350 g (LRF model)
Standard compliance	MIL STD-810 for mechanical and environmental, MIL STD-461 for EMC
